Details
| Basic equipment specifications | |
|---|---|
Standard rail length |
900mm |
PCB width |
50 - 450mm |
PCB thickness |
0.6-5mm |
PCB transportation speed |
700-2000mm/min |
PCB transportation height |
900mm±50 |
Transportation direction |
L→R (R →L) |
Chain type |
Extended pin chain |
Conveyor type |
Chain transmission |
Track fixed edge |
Front fixed |
Power and power |
AC220V 50/60Hz 100W |
Machine size |
900(L)x900(W)x900(H) |
Packing space |
80mm above and below |
Equipment features
- ? Use precision linear bearings and double screws for width adjustment.
- ? Standard (SMEMA) equipped with communication, can be connected online with other devices.
- ? High-precision proximity switch sensor increases equipment sensitivity and usage rate.
- ? There is a return line interface.
